10m TOF Laser Safety Sensor Body Induction Activation For Auto Door System

Detection principle: TOF light flight time lag
The light media: 890 nm infrared laser
Laser laser categories: type I eye safety
The probe response time: 50 ms or less
Detection zone diameter: 100 mm spot class (detection range 2. 8 m)
Farthest detection range: 10 m
Recently cutting distance: 80 cm
Waterproof level: IP67
Working temperature: – 20 ° ~ 60 ° C C
Working voltage: AC/DC 12 ~ 30 v
Standby current: 52 ma (12 v power supply)
Current action: 74 ma (12 v power supply)
Signal output: relay normally open or normally closed
Trigger: mobile and stationary
Function indicators: light-emitting diode, standby for blue, to detect objects in red
The shell material: ABS, PC
