Door Sensor
24G Microwave Door Sensor Alarm Probe for Automatic Door
Availability:
999 in stock
$21.47
- Hign-concerned Chemical: None
- Model Number: GL8
- Brand Name: LIHTNE
- Origin: Mainland China
- Item Type: Exit Button
This product adopts Germany original 24.125GHZ microwave sensor module, not affected by external temperature and humidity and other environmental factors, stable and reliable performance. Intelligent circuit design, greatly improve the sensitivity and stability of the sensing probe, X-Y axis flexible antenna adjustment mode to ensure accurate regional sensing adjustment, high frequency, sensitive and accurate speed.
Product parameters:
Voltage: AC12V-24V, DC12V-30V
Power frequency: 50-60Hz
Power consumption: <2W (VA)
Frequency: 24.125GHZ
Transmitting power: <20db EIRP
Emission frequency density: <5mW/cm²
Installation height: ≤ 4M
Installation angle: 15 °-45 °
Detection mode: motion detection
Detection range:≤4M*2M (When Height is 2.2m)
The detection rate ≥5cm/s
Output signal: relay
Relay output voltage≤AC42V-DC60V
Relay output current≤1A (resistance)
Relay output switching power≤30W (DC) /60VA (AC)
Relay output hold time: 0.5s
Protection level: IP52
Material: ABS
Connection length: 2.5m
Working temperature: -20℃-55℃
Size:142*46*45mm
