Combined Infrared Safety Sensor Radar Activation for Auto Door Control System

• Combined radar activation and infrared safety sensor is used for automatic sliding door,folding door and curver door.Radar technolog is for door activation.Infrared technology is for door safety entrance.

• Have function of background self-learn.Can learn background automatically when power on.Suit all kinds of occasons always self-correction once be influenced by quake,distortion,move,dark and sunshine.Ensure the sensor can work durable.

• Microwave technology adopts the Germany Micorwave sensor module,ignore the influence by temperature and humidity with reliable working performance.

Parameter:

• Power supply: AC/DC12-30V

• Cable Lenght: 2.5m

• Signal Output: Relay

• Max. installation Height: 2500mm

• Static Power: 65mA

• Action Current: 130mA

• Dimension: 260.3Lx53.4Wx44Hmm

• Cover: ABS

Infrared Safety:

• Ray Type: Reflect infrared

• Ray Source: Infrared940mm

• Quantity of Ray: 8 emit rays and 8 receive rays

• Self-learing time: 10s

• Operation Indicate: Standby by Blue LED, action by Red LEd

• Temperature: -40~60C

• Output time: 500ms

• Respond: Less than 100ms

• Optical surface: PMMA

Microwave Activation:

• Technology: Microwave processor

• Frequency: 24.125GHz

• Emission Power: <20dBm EIRP

• Transmission Frequency density: <5mW/cm2

• Detection Mode: Movement

• Detecton Range: 4m(W)x2m(D)

• Output time: 0.5s

• Temperature: -20~55C

Package Included:

• 1 x Combined Radar Activation & Infrared Safety Sensor
