8 Input And 8 Output VGA Matrix Swtich 8×8 Video Switcher RS232 IR Remote Control Auto Loop 1080P Support Tiled Display

Type of the products:VGA0808



Model:VGA0808

Package includes:
1, The matrix
2, power cables
3, RS232 cable
4, Infrared remote controller

5.ComputerControl English software(free)
6, Matrix instructions (downloading)



Product overview:



VGA Series matrix switcher is designed for computer and video display signals and high resolution VGA Digital image design of signal switching, and intelligent high-performance broadband matrix switching equipment, VGA matrix switch is used to switch on the computer the monitor signal and distributionMulti-channel signal from the input channels can be switched to the output on either channel in the channels and between output channels independent of each other. Simply put, is the ability to display any one of multiple input signals to any one of your specified monitor matrix switcher is the way or multi-way audio and video signal transmission to one or more display devices.The products can be widely used in multimedia digital multifunctional auditorium, conference rooms, multimedia teaching, command and control centers, hotels, exhibition hall, large-screen projection display, video works and so on.



Features:

specifications: 8 into 8 out

• 8 channel VGA computer input signal; 8 computer VGA signal output, could well cross switch
• 16-channel audio input, 16-channel audio output (optional), can be synchronized with the video completely cross switch
• Using the latest 32-bit ARM9 embedded processor
• 500M high bandwidth chip, with line driver features
• Developed high-resolution display circuit
• Long distance transmission gain distortion compensation technology
• Digital synchronous recognition processing (DSIP) technology
• Built-in switch round-robin feature can be set arbitrary time interval and channel
• Built-in 32 scene storage function, able to operate directly on the panels or in the infra-red remote sensing
• Circuit using programmable logic array (FPGA), more stable performance
• PC video input and output ends of HD15PIN (VGA) connector
• LCD screen, display devices switches for each channel, you can enter information such as signal, direct and convenient
• This product with locale switching memory protection, LCD liquid crystal display, audio and video synchronization or separate asynchronous switching functions
• This product is an intelligent device with high reliability, fault-tolerant technology adopted in the design of, and uses a high anti-jamming capability of communication interface circuit, ensure reliability of the communication, with infrared remote control and RS232 communication functions, users can complete this presentation of the signal switch
• With RS232 communication interface, you can easily with computers, remote control system or remote control devices used in conjunction
• Compatible with all product codes and instructions
• International designer, can be adapted to AC 110~240V,50/60Hz
• High-quality, mass-produced, there is high compatibility and stability
• Dual serial port loop technology, users no longer worry about lack of serial, many devices can be cascaded up to 256



Multiple control modes

• Button panel control:Panel touch buttons directly through the device switching;
• Infrared remote control: use the remote control the infrared remote control switch;
• Software control: use a dedicated matrix management software-controlled switch,Connection interface with RS232 interface.

Technical parameters:



VGA channels

Input ports: 8 Channels

Output ports: 8 channels



Audio channels (optional)

Audio input ports: 8 channels

Audio output ports : 8 channels



· Bandwidth: 500MHz ( -3dB), fully loaded

· Brightness chromatic interference: -50dB@10MHz

· Signal type: digital VGA, digital TMDS

· Differential-phase-I/0S:<1.28, 3.58MHz

· Differential gain error: 0.1%, 3.58-4.43MHz

· Isolation (crosstalk): <-85dB (10MHz)

· Input signal level: 1.2 Volt p-p,5 volt p-p (TTL)

· Nonlinear distortion: <0.02%/0.02o (RL=150 ohm)

· Supported resolution: HD 480i~1080p/640X480~2048X1536 (60Hz)

· Input/output interface: HD15PIN (VGA)

· Control modes: RS-232, IR, the keyboard Panel

· Control Protocol: 9600 baud, 8 bits, 1 stop bit, no parity

· Input level: 0.7Vp-p

· Input resistance: 75 Ohm

· Output resistance: 75 Ohm

Synchronization channel

· Input level: TTL

· Output level: TTL

· Input impedance: 10K

· Output impedance: 33 ohms

· Sync polarity: follow the input

Product specifications:

· Power AC:110V-240V,50/60Hz

· Power consumption: 20W

· Dimensions: 480 (w) *45 (h) *260 (d) (mm)

· Weight: 4kg

· Rack mounting: 19 inch 1U height

· MTBF mean time MTBF:50000 hours
